High Frequency Induction Heating Machine

Product Abstract:

Power:40KW Frequency:30-80KHZ


wechat:Joanna8608
Chat online wechat:Joanna8608
Product Description

High Frequency Induction Heating Machine

 Main Characteristics:
1 Siemens IGBT module and Inverting technologies of third generation been used; Higher reliability and lower maintenance cost.
2 100% Duty cycle, continuous working is allowed at maximum power output.
3 Display of heating power and heating current and oscillating frequency;
4 Simple to install, Installation can be done by unprofessional person very easily;
5 Light weight
 6 Advantages of the model with timer: The power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability;

Parameter:

Type

HF-40AB

Work Power

3*380v/415v/440v/480v 50-60hz

The range of operating voltage

340-430V AC

Output power

40KW

Input current

40A

Fluctuating frequency

30-80khz

Timing (Heat time,Retain time,Cool time)

1-99S

The flow rate of cooling water

0.15 Mpa 10L/Min

Water temperature protection point

40centidegree

Duty cycle

100% (40degree room temperature)

Weight

Mainparts:42Kg Transformer:32kg

Size

Main Parts: Main Parts:640*350*550mm
Transformer: 510*260*410mm

Advantage:
1 More than ten years experience, stable and goods performance
2 CE certificated
3 Cooperated with CHOW TAI FOOKS, Matsushita, Foxconn, Media, Gree and ZHIGAO Air conditioner.
4 Suitable for a large range, heating, quenching, forging, melting, solding and so on.
5 Siemens IGBT

6 DELIXI Air Switch

7 Phase Bridge( Germany IXYS)

8 Filter Capacitor(Janpanchemi-con)

9 All screws are Stainless Steel

10 Transformer has two or more transformer ratio, flexible connect different induction coils.


Application:
